With its ingenious filter bag arrangement, Venti PowerAirTube achieves a maximum filter area in a minimum of space. For example, air capacities of 90,000 m³/h are achieved on a 13 m² footprint.


Your benefits:

Filter capacities from  8,000 m³/h to 90,000 m³/h in an extremely compact unit.

In the Venti PowerAirTube, the fan is integrated into the unit head on the clean air side. This saves space, as no additional floor space is required.


Your benefits:

Operation of a large-volume dust extraction system is also possible in the smallest of spaces.

Venti PowerAirTube is supplied as a fully assembled unit. There is no need for a separate foundation for the fan or complex connection to the filter unit via pipework. Only the suction and pressure pipework and dust discharge are installed on site. And even the electrics are already pre-assembled, so it really is a plug & play installation.


Your benefits:

Very quick installation at significantly lower costs.

Intuitively positioned inspection openings allow easy inspection and maintenance of all relevant filter components. The filter bags in the Venti PowerAirTube are replaced from the clean gas side. Thanks to highly flexible spring support baskets, this can be done quickly and safely. Overall, the filter is extremely low-maintenance.


Your benefits:

Easier inspection and maintenance saves the time of your employees and customer service.

Venti PowerAirTube impresses with its particularly efficient pressurised pulse purge air cleaning of the filter bags. Cleaning takes place in a sealed unit with only its own process air, so that no separate compressed air connection is required. The use of process air during cleaning eliminates common sources of interference such as condensation, frost or caking on the filter bags.


Your benefits:

Optimal dust removal results - every time.

Thanks to its tangential inlet and optimised filter bag arrangement, Venti PowerAirTube has an integrated, particularly effective cyclone pre-separator. This enables a high degree of separation and customised adjustment of the filter surface to the respective process.


Your benefits:

Safe dedusting even with large amounts of material.


The use of the system's own low-pressure pulses enables particularly gentle cleaning of the filter bags. The permanent measurement of the filter resistance ensures timely cleaning and therefore an optimum service life for all materials.


Your benefits:

Reduced costs for wear material.

The Venti PowerAirTube all-in-one design creates short distances. There are no clean gas collection ducts and pipework to the fan, so there is no energy loss due to resistance in the pipework. Instead, the flow-optimised intake takes place in the fan. An integrated volume flow control system adjusts the fan output as required.


Your benefits:

Reduced energy costs.

Venti PowerAirTube is a convincing overall package that saves you money. Inspections and maintenance can be carried out quickly and easily. The monitored filter function enables preventive measures and ensures smooth operation. Its material-friendly technology increases the service life of consumables. And last but not least: even the energy consumption is reduced thanks to the compact design.


Your benefits:

Sophisticated dust extraction solution with high savings potential.
